Bobcat E35 Compact Excavator (Extendable Arm)
Bobcat E35 Compact Excavator (Extendable Arm)
Bobcat E35 Compact Excavator (Extendable Arm) Information
Part of the R-Series, the Bobcat® E35 compact (mini) excavator is a popular choice in the 3-ton size class. Zero Tail Swing (ZTS) provides unrestricted rotation, greater flexibility and reduced potential for damage to the machine and surrounding property. It’s available with an angle blade option, long arm option or clamp-ready extendable arm option. Upgrade to an Optional 33 hp engine for even more productivity.
Engine
| EMISSIONS TIER (EPA) | Tier 4 |
| ENGINE FUEL | diesel |
| MAXIMUM GOVERNED RPM | 2,550 rpm |
| HORSEPOWER | 24.8 hp |
| TURBOCHARGED ENGINE | not-available |
| OPTIONAL HORSEPOWER | n/a |
Performance
| OPERATING WEIGHT | 8,597 lb |
| WEIGHT CLASS | 3.9 t |
| TRAVEL SPEED | 2.9 mph |
| TRAVEL SPEED - HIGH | 2.9 mph |
| TRAVEL SPEED - LOW | 1.6 mph |
| ARM DIGGING FORCE | 4,478 lbf |
| BUCKET DIGGING FORCE | 6,968 lbf |
| RATED LIFT CAPACITY | 3011 lb |
| LIFT RADIUS | 118 in |
| BOOM SWING - LEFT | 75° |
| BOOM SWING - RIGHT | 55° |
| MAXIMUM DIG DEPTH | 12.9 ft |
| MAXIMUM DUMP HEIGHT | 12.5 ft |
Capacities
| FUEL TANK | 13.7 gal |
Hydraulic System
| AUXILIARY STD FLOW | 16.9 gal/min |
| AUXILIARY PRESSURE | 2,987 psi |
Dimensions
| LENGTH | 190.5 in |
| WIDTH | 69 in |
| HEIGHT | 96.2 in |
| HEIGHT WITH OPERATOR CAB | 96.2 in |
| REACH @ MAXIMUM HEIGHT | 19.7 ft |
List of Features
| AIR CONDITIONING | Optional |
| CAB ENCLOSURE | optional |
| CAB HEATER | optional |
| HEATER / AIR CONDITIONING | optional |
| TAIL SWING TYPE | minimal |
| ENGINE SHUTDOWN | standard |
| AUXILIARY HYDRAULICS | standard |
| SECONDARY AUXILIARY HYDRAULICS | optional |
| RUBBER TRACK | standard |
| SELECTABLE AUXILIARY HYDRAULIC FLOW | standard |
| ANGLE BLADE | optional |
| QUICK TACH SYSTEM | standard |
*Advertised Price Disclaimer: The displayed price is the Suggested List Price (SLP) and may not reflect the final sales price. Current national promotions have been deducted from the SLP, but the actual sales price may vary depending on selected options or accessories. Please consult with our sales team for a personalized quote.
REQUEST A QUOTE
| Manufacturer | Bobcat |
| Product | Compact Excavators |
| Model | E35 25 HP Extendable Arm |
| Condition | New |
| Year | 2022 |
| Horsepower | 24.8 hp |
